20/40 Point Overlay Kit For Lcd Panel Kiosk Usb Driver-Free
Capacitive Touch Screen Ir Touch Frame
| Product Parameter |
| The casing outside the material | PC |
| Appearance of the color | Dark brown |
| Top border width | The 16.7 mm |
| Bottom border width | The 17.7 mm |
| The thickness of the border | The 7.8 mm |
| Built-in glass | 3mm tempered glass |
| Interpolation resolution | 4096 x 4096 |
| Response speed | 5 ms or less |
| Touch the accuracy | Plus or minus 2 mm |
| Input mode | Opaque objects such as fingers and stylus |
| The output form | The coordinate output |
| Theoretical clicks | Unlimited time |
| Minimal touch object | 5mm |
| The interface type | USB |
| The Electronic Properties |
| Sweep frequency | Single point 244Hz, 4 point 55Hz |
| The power supply mode | USB take electricity |
| The power supply voltage | DC + 5 v + / - 5% |
| Working current | < 120 ma |
| Environmental features |
| project | specifications |
Temperature range | Operating temperature: -20℃~50℃ Storage temperature: -20 ° C to 60 ° C |
| Relative humidity | Operating humidity: 10%~ 85% RH, no condensation Storage humidity: 10% to 90% RH, without condensation |
| The light resistance | Resistance to light |
| waterproof | IPX5 |
| Software Features |
| Touch type | Touch at 20 |
| Multi-touch supported operating systems | Windows10/Windows8/Windows7/WindowsXP/Vista/Android /Linux |
| Test data |
| project | The test conditions |
| High temperature, high humidity work | Temperature: 50℃, humidity: 85%RH (no condensation), continuous
work for 24 hours |
| Work in low temperature | Temperature: -20℃, no continuous operation for 24 hours, room
temperature for 2 hours |
| High temperature and high humidity storage | Temperature: 60℃, humidity: 90%RH (no condensation), no continuous
work for 24 hours, room temperature for 2 hours |
| USB | Plug and remove test Windows 7 and Windows 10 are plugged and
removed 1000 times each |
| System restart | Windows 7 and Windows 10 reboot 1,000 times each |
| The basic function | The basic function |
| All the above functional tests have passed |
Product More Details
Item | Interactive Capacity Infrared Multi IR Touch Frame |
| Brand | BENSHI本狮 / bems |
| Application | Indoor |
| panel | LG screen |
| Panel Size | 32/43/50/55/65/75/85/98 Inch |
| Screen Resolution | 1080*1920 2k / 4k / full hd |
| CMS | we have our digital signage Signworld cms software |
Customized | factory support OEM, SDK,logo,color,style design |
Supplier Type | Original manufacturer |
Our service | 1-3 years warranty, free parts |
Place of Origin | guangzhou /shegnzhen/foshang of china |
Specification | Digital Poster |
Certificate | CE/CCC/FCC/ROHS/ISO9001 |
| Installation | floor standing |
Input Voltage | 110-240 V |
Contrast Ratio | 1200:1 |
Interface | USB |
Viewing angle | 89/89/89/89, full view |
| Use/Application | advertising publish, retail store, shopping mall, display of
dishes, welcome display, self-service business, exhibition hall,
wayfinding, airport, subway, elevator, Restaurant & Hotel Supplies,
education, medical treatment, supermarket, bus station, hospital media company, software cpmpany,
Construction company, government project |
| Key Words | lcd digital signage, vending machine, digital signage and displays, tv, tv smart,
monitor, advertising screen, advertising equipment, software,
display screen, touch screen, lcd panel, led screen, totem,
advertising display, digital totem kiosk, advertising player, ad
player kiosk |
Function Display
Our company specializes in producing indoor/outdoor digital signage
advertising screens, all in one
interactive touch kiosk and all kinds of customized styles.
You can use the U disk to play or by remote computer push release.
U Disk Playback: You can connect to WiFi and the internet. Open the software on
the machine, upload
pictures and videos to the USB drive, and plug it in to
automatically load the pictures and videos.
Remote Playback: We have our CMS software, and you can put 2 or 3 or more screens
side by side and
stitch the visuals together to make one big screen. You can also
create split-screen pictures and videos to
play, customize and select different module settings, and play
pictures, videos, texts, etc. at the same time.
There are also touch versions available for Android / Windows.
Touch LCD Screen: you can download Google Mall, Google Browser and other
applications or app software.
Android System: 2G(ram)+16G(rom)
Windows System: i3/i5/i7 8G(ram)+256G(rom)
If you want to know more detail, plz no hesitate contact me.
Details Show
Company Profile
Guangzhou Bems Electronics Co.,Ltd. was founded in 2012. We focus
on designing, researching and developing,
manufacturing and selling advertising player,digital signage,all in
one pc,touch screen kiosk,bus monitor,TV,LCD/LED
monitor and so on. We have more than 1000pcs of self-developed
designs and molds for you to choose from. We
release at least 10 new products monthly to meet the latest market
trends. With our rich experience and considerate
services, we have been recognized as a reliable supplier for many
international buyers. We operate our in-house
facilities to work on your OEM/ODM projects, enabling us to meet
your customized requirements. With an annual
production capacity of 10,000,00pcs, we can fill your bulk orders
with ease.
To ensure quality, we have more than 10 QC members to carry out
strict inspection at each stage: incoming inspection
(IQC), in-process inspection (IPQC) and final inspection (FQC).
We have also introduced machines which allow us to make products
that meet international standards. Our products
sell well in domestic and international markets, such as the USA,
and are favorably appraised by clients. To benefit
from our strong OEM/ODM capabilities and considerate services,
contact us today. We will sincerely create and share
success with all clients.
